Lake People DIGI-TOOL F611

Delivery time approx. 2 - 3 days after receipt of order

Item number: 1006251
EAN: 4262404460217

1,049.90EUR *

incl. VAT plus shipping costs

2 x 1 in 4 AES/EBU SPLITTER more

Close menu

digitaler Verteilverstärker für AES/EBU Signale
2 Eingängen und 8 Ausgängen
zwei identischen Modulen mit 1 Eingang und 4 Ausgängen
Intern geschaltet auch 1 in 8

- 2 modules each with 1 input and 4 outputs - Inputs and outputs transformer balanced, impedance... more

Close menu

- 2 modules each with 1 input and 4 outputs
- Inputs and outputs transformer balanced, impedance 110 ohms via XLR sockets according to AES 3/11
- High sensitive inputs to regenerate unproper or weak input signals
- High output voltages to drive long distances

- Failsafe operation through switchable Auto-Mode Multimode power supply 90 … 260V AC
- 19”, 1 U stainless steel case, front dark grey

MULTI-SYNC UNIT OPTION:
The MULTI-SYNC UNIT option offers the following features:
- 3 external inputs, sample rate 28 ... 210 kHz: AES/EBU, AES-id, WCLK
- 1 AES-EBU sync output
- Internal oscillators with 32, 44.1, 48, 88.2, 96, 176.4, 196 kHz
- Auto-Mode, Format, Key-Lock und Mute switchable
- Displays for: Sync-Source, Sample-Rate, Lock, Error, Mute, Pro/Con- Format, Auto-Mode, Key-Lock

Close menu

dimensions:	483 x 44 x 166 mm (WxHxD)
housing form:	19" / 1 HE
AES/EBU I/O:	2 / 8 (XLR)
bit depth:	24 Bit
output impedance:	110 Ohm
Input Sensitivity:	< 200 mV
Input Impedance:	110 Ohm
additional features:	optionale Multi-Sync Option verfügbar
sample rate:	max. 192 kHz
power supply:	Internal 230 V / 115 V AC
